UM-401-700 Ultra Heavy Duty Half Capper Machine
UM-401-700 Ultra Heavy Duty Half Capper Machine
UM-401-700 Ultra Heavy Duty Half Capper Machine
The UM-401-700 capper is designed to sew any thickness of panel to a quilter border. “If you can flange the panel we can 1/2 cap it to create buckets.”
Product Information
Technical Details
Catalog
Walking foot mechanism
Needle positioning
Retractable binder assembly
Automated foot lift
Max sewing speed (rpm)
3600
Recommended sewing speed (rpm)
3200
Stitches per inch (spi)
4-5″ (6.4-5mm)
Presser foot height
39/64″ (15.5mm)
Needle type
135×17
Needle size
22-24
Voltage/phase
220/1
Current (amps)
15
Air pressure (psi)
80 (5.5 bar)
Air consumption (cfm)
0.1 (3 L/min)
Production (units/minute, hour or shift)
1/min
Max panel thickness
2 1/2″ (64mm)
Min panel thickness
flat
