UM-BMC-3300 Border Measure Cut Machine

UM-BMC-3300 Border Measure Cut Machine

The UM-BMC-3300 will measure, mark and cut borders to a pre-programmed length. The marking attachment allows you to mark location for handles or labels. Handles up to 99 SKU’s Marking attachment Accuracy to +/- 1/8″ (3mm) Touch screen Yield: 120′ per min Material thickness 1/2″ (12.7mm)

Product Information
Technical Details
Machine Video
Catalog

Handles up to 99 SKU’s
Marking attachment
Accuracy to +/- 1/8″ (3mm)
Touch screen
Yield: 120′ per min
Material thickness 1/2″ (12.7mm)

Max feed speed	80’/min (24m/min)
Approximate cycle time per queen	Measure/cut only – 10 sec
Max material thickness	1/2″ (12.7mm)
Min material thickness	flat
Max material width	18″ (450mm)
Yield	4 units/minute
Accuracy	+/- 1/8″ (3mm)
Voltage	220 (alternative voltages available)
Current (amps)	6
Air pressure (psi)	80
Air consumption (cfm)	0.5
